IP 66 Rating UHF RFID Antenna

ANT800-US/ANT800-EU

ANT800 is built under slim and compact design concepts and is a perfect match for PROMAG's UHF RFID readers. Its compact design makes it the best choice for applications where space is limited. Welcome to discuss with our sales reps.

▌Features

Circular polarization
Slim and compact ID housing for any space installation
Up to 5 meters reading distance depending on types of tags
Compatible with different international UHF spectrum (or bandwidths)

▌Specification

Input Impedance	50 ohms
VSWR (Voltage Standing Wave Ratio)	1.5
Antenna Gain	9 dBi +/- 0.5
Axial Ratio	Under 3dB
Frequency Range	865-869 MHz, 902-928 MHz, or customizable
Cable (N-Type to SMA)	3M (standard) or customizable
RF Connector	N-Type
Input Power	10 Watts
Polarization	RHCP (standard) or LHCP
IP Rating	IP66
Temperature Range	Operating Temp: -30 °C ~ +55 °C; Storage Temp: -30 °C ~ +65°C
Humidity	10%~ 85% non-condensing
Dimension	25.6 (L) x 26.6 (W) x 3(H) cm
Safety Approval	RoHS & REACH

*Specification is subject to change without notice.

▌Applications

Inventory control
Assets tracking
Access control
Parking lot application
Files or items tracking

▌Available Versions

ANT800-US: 902-928 MHz
ANT800-EU: 865-869 MHz

*Customized Antenna options: Patch type, PIFA type, and Array type are available on request.
